Air Pollution Prevention Facilities
CYCLONE BAG FILTER DUST COLLECTOR
CCF series
As an integrated form of cyclone and a bag filter dust collector, this product ensures great filtering efficiency by filtering dust through cyclone first and then with a bag filter.
APPLICATION
Useful in work sites where a large amount of dust and chips are present or generated.
Styrofoam dust, Paper dust, Wood dust, Fiber dust, etc.
※This product can be customized in a variety of shapes to suit your use and installation site.
FEATURES
- Ensures great dust collection and filtering efficiency because cyclone in the suction part collects large or heavy particles first and remaining dust flows into the dust collector.
- Minimizes an installation space and reduces installation costs by integrating cyclone and a dust collector.
- Effective in collecting and filtering light, gluey and absorptive dust because the product is designed to push the dust into a bag filter.
- Effective in collecting and filtering gluey, paper, Styrofoam and light dust because dust falls due to a descending air current.
- Filters dust (0.5㎛ or larger) by more than 99%, using a broad cylindrical bag filter.
- Cleans a filter by spraying high-pressure air through an air pulse system and maximizes filtering efficiency.
- Ensures powerful suction, using a high-efficiency turbo fan.
- Stops the operation automatically when needed to check or change a filter and notifies a warning by buzzer.
- Easy maintenance with consumable parts at the front of the product.
- Keeps dust collection highly efficient through automatic filter cleaning (by air pulse system) after operation.
- Able to handle the dust collected in a dust box in a safe and convenient manner without secondary contamination.
- Able to manage an air pulse system and check a filter in addition to easy operation, using a main control panel.
- Easy filter maintenance, using a differential pressure gauge.
CAUTION
- This product is not suitable for wet or oily dust.
- To collect special dust (e.g., high-temperature dust, spark, explosive dust/gas, etc.), please contact us for a consultation before placing an order.
- An air compressor should be connected to use the filter cleaning system (air pulse system).
